Cvmnkljfge T.RD8503.03 Universal LCD LED TV Controller Driver Board TV/PC/VGA/HDMI/USB+7 Key Button+2ch 6bit 30pins LVDS Cable+1 Lamp Inverter for Arduino  Starter  Kit

Cvmnkljfge T.RD8503.03 Universal LCD LED TV Controller Driver Board TV/PC/VGA/HDMI/USB+7 Key Button+2ch 6bit 30pins LVDS Cable+1 Lamp Inverter for Arduino  Starter  Kit: Computers & Accessories. Cvmnkljfge T.RD8503.03 Universal LCD LED TV Controller Driver Board TV/PC/VGA/HDMI/USB+7 Key Button+2ch 6bit 30pins LVDS Cable+1 Lamp Inverter for Arduino  Starter  Kit: Computers & Accessories. 1. Put the firmware of "SKR8503_100.bin" in formatted USB flash disk(FAT32), then insert the USB disk and the 7KEY-Button to the board 。 2. After turn on the power, the light of the 7key button be Red then flash red faster. 。 IT KEEPS flashing and NEVER STOP. it's normal, just wait about 1 minute, it means upgrade has finished. then power off and pull off the u-disk. (Note that write programs do not power outages, crashing won't be able to use) 。 According to the original factory specifications, perfect fit in. 。 A wide range of applications: This module can be applied to Arduino Robot, Household Power Systems, raspberry pie and DIY Servo Shield Module etc. 。 Description:。Model: T.RD8503.03。Tuner: RDA5160。Scheme of the chip: 8503。TV Format: Analog Signal。Support Language: Russian, English, Hindi, Simplified Chinese, Khmer, Vietnamese, Myanmar, French, German, Italian, Spanish.。Input Interface: PC / HDMI / TV / AV / USB multimedia playing。Power Adapter: DC 12V 3-5A。Screen interface: LVDS Double 6。Screen voltage: 3.3V / 5V / 12V (Jump cap)。Resolution: Support high screen 1920 * 1080, 8.9-42 inch LVDS screen (support most of the panels, but not all)。Not only USB interface can be used to upgrade programs, but also can use to play video/music/photo, basically, formats are supported. You can also set a boot display pictures or LOGO and Mirror Enable.。How to know if your panel suitable for this board?。Step 1: Find your LCD model's resolution (you can check the resolution from this link: http://www.panelook.com/index.php)。Step 2: Find and write in the corresponding firmware.。You can download the firmware from here: http://myosuploads3.banggood.com/products/20181221/20181221022350DANGKOURR52C04A.rar。Programming:。1. Put the firmware of "SKR8503_100.bin" in formatted USB flash disk(FAT32), then insert the USB disk and the 7KEY-Button to the board。2. After turn on the power, the light of the 7key button be Red then flash red faster.。IT KEEPS flashing and NEVER STOP. it's normal, just wait about 1 minute, it means upgrade has finished. then power off and pull off the u-disk. (Note that write programs do not power outages, crashing won't be able to use)。Package included:。1 x Controller Board 。1 x English Remote control。1 x IR。1 x 7 key button。1 x 2ch 6bit 30pins lvds cable 250mm length (You can replace the screen line as needed.)。1 x 1pcs CCFL inverter with 3.5mm pin pitch。Note: 。The IR & KE 。 。 。
